Name: Pipes

Display Field: SEGMENT_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description:

Service Item Id: ae906d307c7d4702849dad7b18bd7862

Copyright Text: https://levees.sec.usace.army.mil/

Default Visibility: true

MaxRecordCount: 2000000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 1000000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: NaN
YMin: NaN
XMax: NaN
YMax: NaN
Spatial Reference: 4269  (4269)  VCSWkid(105703)  LatestVCSWkid(6360)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [168, 168, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SE_ANNO_CAD_DATA ( type: esriFieldTypeBlob, alias: SE_ANNO_CAD_DATA )
• SEGMENT_ID ( type: esriFieldTypeDouble, alias: SEGMENT_ID )
• SEGMENT_NAME ( type: esriFieldTypeString, alias: SEGMENT_NAME, length: 100 )
• SYSTEM_ID ( type: esriFieldTypeDouble, alias: SYSTEM_ID )
• SYSTEM_NAME ( type: esriFieldTypeString, alias: SYSTEM_NAME, length: 75 )
• PIPE_ID ( type: esriFieldTypeString, alias: PIPE_ID, length: 20 )
• LEVEE_STATION_CODE ( type: esriFieldTypeString, alias: LEVEE_STATION_CODE, length: 20 )
• MATERIAL ( type: esriFieldTypeString, alias: MATERIAL, length: 100 )
• DIAMETER_INCHES ( type: esriFieldTypeDouble, alias: DIAMETER_INCHES )
• GRAV_V_PRESS ( type: esriFieldTypeString, alias: GRAV_V_PRESS, length: 25 )
• FUNCTION ( type: esriFieldTypeString, alias: FUNCTION, length: 25 )
• CONSTRUCTION_YEAR ( type: esriFieldTypeSmallInteger, alias: CONSTRUCTION_YEAR )
• INLET_INVERT_ELEVATION_FEET ( type: esriFieldTypeDouble, alias: INLET_INVERT_ELEVATION_FEET )
• OUTLET_INVERT_ELEVATION_FEET ( type: esriFieldTypeDouble, alias: OUTLET_INVERT_ELEVATION_FEET )
• SURVEY_DATE ( type: esriFieldTypeDate, alias: SURVEY_DATE, length: 8 )
• DATA_SOURCE ( type: esriFieldTypeString, alias: DATA_SOURCE, length: 100 )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• RESPONSIBLE_ORGANIZATION ( type: esriFieldTypeString, alias: RESPONSIBLE_ORGANIZATION, length: 255 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
